Non-magnetic Drill Collar
● Txuj: API Spec.7-1,5DP thiab NS-1
● Cov khoom tsis sib nqus sib npaug rau P530, P550 & P650
● Cov khoom tsis sib nqus loj ntawm 3 1/8" mus txog 11"
● Non-magnetic Drill Collar, Laum yeeb nkab & HWDP
Hauj lwm lawm
Vigor Non-Magnetic Drill Collars - Koj lub chaw tsim khoom ntseeg siab rau Drilling Operations
Vigor yog cov chaw tsim khoom thiab cov chaw muag khoom zoonon-magnetic laum dab tshossiv nyob rau hauv cov roj thiab roj drilling kev lag luam thoob ntiaj teb. Peb yuav nthuav qhia rau koj txog cov qauv, kev xaiv cov khoom siv, thiab hom uas peb tuaj yeem muab tau rau hauv cov khoom siv roj av. koj tuaj yeem tau txais cov kev daws teeb meem drilling thiab casing.
(1) Txuj: API Spec.7-1,5DP thiab NS-1
Peb cov khoom tsim thiab tsim raws li API Spec 7-1 thiab ua raws li cov qauv thoob ntiaj teb xws li 5DP thiab NS-1, uas nws lub cev tsim muab cov tuab, hwm laum dab tshos phab ntsa tsim kom muaj zog thiab tiv thaiv kev tawg lossis twisting. Cov pas nrig muaj lub zog muaj zog threaded lub thawv thiab tus pin sib txuas kom ntseeg tau tias xa cov torque thiab axial loads yam tsis ua haujlwm.
(2) Khoom siv
Vigor siv lub zog siab uas tsis yog-magnetic alloys suav nrog P530, P550, thiab P650 los tiv thaiv kev kub ntxhov thiab kub hauv qhov chaw hnyav downhole. Peb cov khoom uas tsis yog hlau nplaum tiv thaiv kev cuam tshuam nrog MWD cov cuab yeej rau qhov tseeb qhov chaw zoo thiab kev soj ntsuam, thiab qhov loj ntawm 3 1/8" mus txog 11", nws tau ua kom zoo nrog cov tshuaj lom neeg muaj pes tsawg leeg, tshwj xeeb tshaj yog forged kom ua tiav cov khoom siv zog siab. cov khoom thiab tsis tshua muaj hlau nplaum permeability, zoo heev intergranular corrosion cracking kuj, thiab hnav tsis kam.
(3) Hom Vigor tuaj yeem muab Drilling dab tshos
Peb muab ntau yamAPI 7-1 Tsis-Magnetic Drill Collarhom xws li kauv, thiab slick dab tshos. Kauv dab tshos txo txoj kev nyiam nyob rau hauv kab rov tav thiab cov qhov dej sib txawv heev. Slick dab tshos tso cai rau kev sib hloov ceev dua. Cov kev xaiv kev cai thiab cov alloys muaj tswv yim muaj. Technical parameters muaj.
Slick Drill dab tshos
|
O.D. |
I.D. |
Ntev mm |
Style ntawm kev sib txuas |
Bevel txoj kab uas hla mm |
Bending zog piv |
||
|
mm |
Hauv. |
mm |
Hauv. | ||||
|
79.4 |
3-1/8 |
31.8 |
1-1/4 |
9150 |
NC 23-31 |
76.2 |
2.57:1 |
|
88.9 |
3-1/2 |
38.1 |
1-1/2 |
9150 |
NC 26-35(23/8IF) |
82.9 |
2.42:1 |
|
104.8 |
4-1/8 |
50.8 |
2 |
9150 |
NC 31-41(27/8IF) |
100.4 |
2.43:1 |
|
120.7 |
4-3/4 |
50.8 |
2 |
9150 |
NC 35-47 |
114.7 |
2.58:1 |
|
127.0 |
5 |
57.2 |
2-1/4 |
9150 |
NC 3850 (31/2IF) |
121.0 |
2.38:1 |
|
152.4 |
6 |
57.2 |
2-1/4 |
9 150 o9450 |
NC 44-60 |
144.5 |
2.49:1 |
|
158.8 |
6-1/4 |
57.2 |
2-1/4 |
9 150 o9450 |
NC 44-62 |
149.2 |
2.91:1 |
|
158.8 |
6-1/4 |
71.4 |
2-13/16 |
9 150 o9450 |
NC 46-62(4IF) |
150.0 |
2.63:1 |
|
165.1 |
6-1/2 |
57.2 |
2-1/4 |
9 150 o9450 |
NC 46-65(4IF) |
154.8 |
2.76:1 |
|
165.1 |
6-1/2 |
71.4 |
2-13/16 |
9 150 o9450 |
NC 46-65(4IF) |
154.8 |
3.05:1 |
|
171.4 |
6-3/4 |
57.2 |
2-1/4 |
9 150 o9450 |
NC 46-67(4IF) |
159.5 |
3.18:1 |
|
171.4 |
6-3/4 |
71.4 |
2-13/16 |
9 150 o9450 |
NC 50-67(41/2IF) |
159.5 |
2.37:1 |
|
177.8 |
7 |
57.2 |
2-1/4 |
9 150 o9450 |
NC 50-70(41/2IF) |
164.7 |
2.54:1 |
|
177.8 |
7 |
71.4 |
2-13/16 |
9 150 o9450 |
NC 50-70(41/2IF) |
164.7 |
2.73:1 |
|
184.2 |
7-1/4 |
71.4 |
2-13/16 |
9 150 o9450 |
NC 50-72(41/2IF) |
169.5 |
3.12:1 |
|
196.8 |
7-3/4 |
71.4 |
2-13/16 |
9 150 o9450 |
NC 50-77 |
185.3 |
2.70:1 |
|
203.2 |
8 |
71.4 |
2-13/16 |
9 150 o9450 |
NC 50-80 |
190.1 |
3.02:1 |
|
209.6 |
8-1/4 |
71.4 |
2-13/16 |
9 150 o9450 |
6 5/8 REG |
195.7 |
2.93:1 |
|
228.6 |
9 |
71.4 |
2-13/16 |
9 150 o9450 |
NC 61-90 |
212.7 |
3.17:1 |
|
241.3 |
9-1/2 |
76.2 |
3 |
9 150 o9450 |
7 5/8 REG |
223.8 |
2.81:1 |
|
247.6 |
9-3/4 |
76.2 |
3 |
9 150 o9450 |
NC 70-97 |
232.6 |
2.57:1 |
|
254.0 |
10 |
76.2 |
3 |
9 150 o9450 |
NC 70-100 |
237.3 |
2.81:1 |
|
279.4 |
11 |
76.2 |
3 |
9 150 o9450 |
8 5/8 REG |
266.7 |
2.84:1 |
※ Laum dab tshos tuaj yeem kho raws li tus neeg siv khoom tsim.
Spiral Drill dab tshos
|
OD (hauv.) |
4-3/4 |
6-1/4 |
6-3/4 |
7-1/4 |
7-1/2 |
8 |
9-1/2 |
10 |
11 |
|
Qhov tob ntawm qhov txiav (hauv.) |
7/32 ±1/32 |
9/32 ±1/16 |
5/16 ±1/16 |
11/32 ±1/16 |
11/32 ±1/16 |
3/8 ±1/16 |
13/32 ±3/32 |
7/16 ±3/32 |
15/32 ±3/32 |
|
Spiral Pitch (hauv.) |
38 ±1 |
42 ±1 |
46 ±1 |
64 ±1 |
64 ±1 |
68 ±1 |
72 ±1 |
76 ±1 |
80 ±1 |
※ Laum dab tshos tuaj yeem kho raws li tus neeg siv khoom tsim.
Mechanical Properties
|
Mechanical zog |
Specification |
|
Tensile zog, Mpa |
Ntau dua lossis sib npaug rau 1035 |
|
Yield zog, Mpa |
Ntau dua lossis sib npaug rau 965 |
|
Elongation,% |
Ntau tshaj los yog sib npaug rau 20 |
|
Kev txo qis hauv cheeb tsam,% |
Ntau dua lossis sib npaug li 50 |
|
Charpy Impact Work, J |
Ntau dua lossis sib npaug li 122 |
|
Brinell Hardness (25.4 hli), HB |
Ntau dua lossis sib npaug li 290 |
|
Sib nqus Gradient, μT |
±0.05 |
Kev ua haujlwm ntawm Tsis-Magnetic Drill Collars
Txij li tag nrho cov khoom siv sib nqus ntsuas ntsuas qhov taw qhia ntawm lub qhov dej los ntawm kev ntsuas lub ntiaj teb cov hlau nplaum ntawm lub qhov dej, nws yog qhov tseem ceeb rau cov cuab yeej no nyob rau hauv ib puag ncig uas tsis yog hlau nplaum. Txawm li cas los xij, thaum lub sij hawm drilling txheej txheem, cov cuab yeej drilling feem ntau muaj cov hlau nplaum, uas ua rau muaj qhov sib nqus, yog li cuam tshuam rau cov khoom siv sib nqus. Qhov kev cuam tshuam no tiv thaiv kom tau txais cov ntaub ntawv ntsuas qhov tseeb ntawm qhov chaw zoo. Cov dab tshos uas tsis yog sib nqus tau ua haujlwm los tsim kom muaj qhov chaw tsis sib nqus, khaws cia cov yam ntxwv ntawm cov dab tshos tsis tu ncua.
Lub hauv paus ntsiab lus ntawm kev khiav hauj lwm ntawm cov dab tshos uas tsis yog sib nqus yog ua raws li qhov tseeb tias qhov cuam tshuam sib nqus cov kab saum toj thiab hauv qab ntawm lub dab tshos laum tsis cuam tshuam rau qhov ntsuas qhov chaw. Yog li ntawd, qhov kev tsim no tsim kom muaj qhov chaw tsis sib nqus rau cov khoom siv sib nqus, kom ntseeg tau tias cov ntaub ntawv tau los ntawm cov cuab yeej no raug suav hais tias yog cov ntaub ntawv los ntawm lub ntiaj teb magnetic teb.
Non-Magnetic Drill Collar rau Directional Drilling
Cov qauv ntawm cov dab tshos uas tsis yog sib nqus yog zoo ib yam li cov tho dab tshos tsis tu ncua, nrog qhov sib txawv tseem ceeb hauv lawv cov tshuaj muaj pes tsawg leeg thiab cov khoom siv kho tshuab. Cov khoom tsis sib nqus yog cov cuab yeej tshwj xeeb uas siv rau hauv cov phiaj xwm kev taw qhia.
Nyob rau hauv kev taw qhia drilling, thaum siv ib tug sib nqus inclinometer los ntsuas qhov inclination thiab azimuth ntawm lub qhov dej, nws yog ib qho tseem ceeb rau nruab ib txoj hlua laum nrog ib qho ntev ntawm cov dab tshos tsis sib nqus. Qhov no ua kom lub compass tsis cuam tshuam los ntawm magnetic teb ntawm lub laum txoj hlua thiab yog positioned kom raug nyob rau hauv lub tsis-magnetic dab tshos rau qhov tseeb inclinometer ntsuas.
Vim li cas thiaj xaiv Vigor?
(1) Zoo thiab kev ntseeg siab:
Vigor tswj xyuas cov qauv nruj nruj rau txhua yam khoom. Peb cov dab tshos uas tsis yog sib nqus tau raug tshuaj xyuas tus kheej thiab kuaj xyuas kom pom qhov tsis xws luag thiab ua kom muaj kev ua raws li API thiab cov neeg siv khoom tshwj xeeb ua ntej xa khoom. Peb muab cov ntaub ntawv ua tiav cov ntaub ntawv xeem thiab cov ntaub ntawv tshuaj xyuas thaum thov.
(2) Peb cov khoom lag luam loj tso cai rau lub sijhawm xa khoom sai thiab cov lus teb sai rau qhov kev xav tau sai. Tag nrho cov laum dab tshos tau ntim ruaj ntseg rau kev thauj mus los los tiv thaiv kev puas tsuaj. Peb tuaj yeem npaj cov kev pabcuam thib peb thiab kuaj yog tias xav tau.
(3) Nrog rau kev lag luam dav dav muab cov tswv lag luam loj thiab cov tuam txhab kev pabcuam thoob ntiaj teb, Vigor yog koj tus khub txhim khu kev qha raunon-magnetic laum dab tshosthiab tag nrho cov khoom siv drilling xav tau. Hu rau peb pab neeg tshaj lij hnub no los tham txog koj cov kev xav tau tshwj xeeb.
FAQ
Q: Dab tsi yog qhov txheeb ze permeability ntawm koj cov khoom tsis sib nqus?
Q: Dab tsi yog lub luag haujlwm ntawm cov dab tshos tsis sib nqus rau kev taw qhia drilling, thiab thaum twg nws yuav tsum tau siv dab tshos?
