Slick Line Unit Composition muaj dab tsi?

Daim Ntawv Ntxiv 1 – Slick Line Unit Composition (Surface Equipment)

Yam khoom

Kev piav qhia

A

Txuj

Slick kab Unit

specification

Slick kab ib lub nruas chav tsev nrog kev sib koom ua ke crane yuav tsum ua haujlwm nrog 7000 meters ntawm 0.125" stainless hlau xaim thiab nrog qhov ceev ntawm 2 m / min. Crane yuav tsum muaj peev xwm nqa / ncua 8 pob qij txha ntawm 5 ½ "lubricators ' qhov hnyav thiab txuas ntxiv ntawm 30ft vojvoog nrog qhov siab yam tsawg kawg nkaus ntawm 85 ft., hauv qab-hook qhov siab muaj.

16" X 0.125" Sheave log sib dhos nrog ob qhov tuav.

3, 000 lbs kev nyab xeeb ua haujlwm.

2 Integrated explosion-proof CCTV system (Inside cabin & sab nraud) streamlining rau hauv paus thiab chaw ua hauj lwm.

Chav tsev yuav tsum tsis pub tshaj qhov ntev thiab qhov dav uas tso cai rau ROP escort ntawm chav tsev raws li tau teev tseg hauv SP2000

Cov chaw saib xyuas kev noj qab haus huv raws li tau piav qhia hauv Tshooj 1.7.1.5 ntawm no.

Ntse saib system (1 Sec. nyeem) qhov tob, sijhawm, qhov hnyav, ceev.

Interlock system tswj qhov tob thiab qhov hnyav.

Cabin nrog AC, teeb pom kev zoo thiab kev nyab xeeb pem hauv ntej iav.

Mechanical & Electronic qhov tob txee System

Martin Decker & Electronic weight Indicators.

B

Hnyav plaub ntug (HD)

Slick kab Unit

specification

Lub luag haujlwm hnyav ob lub nruas nrog kev sib koom ua ke yuav tsum ua haujlwm nrog 7000 meters ntawm 0.125" stainless hlau xaim thiab nrog 7000 meters ntawm 0.160" stainless hlau xaim thiab nrog tsawg kawg nkaus ceev ntawm 2 m / min. Crane yuav tsum muaj peev xwm nqa / tshem tawm 8 pob qij txha ntawm 5 ½ "lubricators qhov hnyav thiab txuas ntxiv ntawm 30ft vojvoog nrog qhov siab tsawg kawg nkaus ntawm 85 ft., hauv qab-nqus qhov siab muaj. Xa rau PR-1034.

Lub HD chav tsev yuav tsum muaj peev xwm mus txuas ntxiv rub qhov tsawg kawg nkaus ntawm 4, 000 lb nrog tag nrho nruas ntawm 0.16" hlau. Xa mus rau PR-1034

Sheave log sib dhos rau 16 "X 0.16" xaim nrog ob qhov tuav.

2 Integrated explosion-proof CCTV system (Inside cabin & Outside) streamlining rau hauv paus thiab chaw ua hauj lwm.

Chav tsev yuav tsum tsis pub tshaj qhov ntev thiab qhov dav uas tso cai rau ROP escort ntawm chav tsev raws li tau teev tseg hauv SP2000

Cov chaw saib xyuas kev noj qab haus huv raws li tau piav qhia hauv Tshooj 1.7.1.5 ntawm no.

Ntse saib system (1 Sec. nyeem) qhov tob, sijhawm, qhov hnyav, ceev.

Interlock system tswj qhov tob thiab qhov hnyav.

Cabin nrog AC, teeb pom kev zoo thiab kev nyab xeeb pem hauv ntej iav.

Mechanical & Electronic qhov tob txee System

Martin Decker & Electronic weight Indicators.

C

Slick kab Lwm Cov Khoom Siv

(Siv rau Standard thiab Heavy Duty Units)

Txhua chav tsev yuav tsum nruab nrog:

Ib txheej ceev Test Sub ntawm ob qhov ntau thiab tsawg (3 ½ "& 4 ½").

Ib txheej ntawm Liquid Seal Sub ntawm ob qhov ntau thiab tsawg (3 ½ "& 4 ½").

Ib txheej ntawm shear RAM ntawm ob qhov ntau thiab tsawg (3 ½ "& 4 ½").

Ib txheej ntawm 10K ob chav RAM BOP ntawm ob qhov ntau thiab tsawg (3 ½ "& 4 ½").

Peb (3) teeb ntawm 8 ko taw sib koom ua ke Lubricators ntawm ob qhov ntau thiab tsawg (3½", 4½").

Ib lub cuab yeej catcher rau txhua qhov ntau thiab tsawg (3 ½ "& 4 ½").

Ob txheej ntawm 16 "Shave wheels los ua ke nrog ob qhov tuav.

Mounted tswj module nyob rau hauv alarm kom khiav BOP rams nrog Hydraulic accumulators yuav tsum tau haum rau kaw BOP raws li ib tug SP-1213 thiab API RP 16ST.

Ob txheej ntawm 8'X4' portable Fiber iav cellar grating thiab nkag ntaiv nrog tiv thaiv ncej.

Tag nrho cov saum toj no yuav tsum tau plhaub yog siv rau PR-1034 & SP-1213.

D

Christmas tsob ntoo Access Equipment

Oilfield specifications scaffolding thiab qhov siab siab tshaj 1.2 meters.

Ob txheej ntawm 8'X4' portable Fiber iav cellar grating thiab nkag ntaiv nrog tiv thaiv ncej.

Teeb pom kev zoo rau 24 teev ua haujlwm - haum rau thaj chaw muaj kev phom sij.

E

Kev ncaj ncees kuaj lub tshuab lubricator twj tso kua mis

High-pressure low-volume / low-pressure high-volume pump Unit rau kev ntsuam xyuas kev ncaj ncees ntawm Wellheads thiab siab test lubricators qhov dej:

130 Ltr ib min / 100 PSI

2.2 Ltr ib min/10, 000 PSI

2000 liter dej tank

Recorder (Cov ntaub ntawv lossis daim ntawv qhia)

10K Piping / Hose ntawm Chav thiab Wellhead

Pleev-tawm yeeb nkab / Hose, Choke thiab Valve

F

Roj twj tso kua mis

Kev kub siab hydraulic roj twj tso kua mis rau lub taub hau valve.

G

Hla mus

Hla dhau los ntawm lub taub hau zoo mus rau Cov Neeg Ua Haujlwm Cov Khoom Siv raws li lub tuam txhab teeb tsa zoo. Tshiab 10K & 15K qhov dej yog nrog flanged kev twb kev txuas thaum qub 10K & 15K qhov dej nrog ntoo hau.

Tag nrho cov nqaj twj tso kua mis tshiab Christmas ntoo yog nrog flanged kev twb kev txuas thaum lub qub yog nrog ntoo hau. Xa mus rau Tuam Txhab phau ntawv ua tiav.

Daim Ntawv Ntxiv 2 – Slick Line Unit Composition (Cov Cuab Yeej Hauv Qhov Ncauj)

Yam khoom

Cov cuab yeej

Loj

Lus hais

1

Rope Socket

1 ¼"-1 7/8"

QLS thiab SR kev sib txuas

2

Swivel Sub

1 ¼"-1 7/8"

3

accelerator

1 7/8" -2 1/8"

4

Qe

1 ¼"- 2 1/8"

suav nrog tungsten carbide

5

Knuckle sib koom

1 ½" – 1 7/8"

QLS thiab SR kev sib txuas

6

Linear tube thawv

1 ¼" -2 1/8"

7

Heavy tubular thawv

1 ¼"- 2 1/8"

8

Lub thawv caij nplooj ntoos hlav

1 ¼" -2 11/16"

9

Hydro mechanical thawv

1 ½" -1 ¾"

10

Spang thawv

1 ½"- 1 7/8"

LS, SS (QLS)

11

Hla mus

Txhua yam

12

Plugs & prong rub & teeb tsa cuab yeej

2 3/8"- 5 7/8"

DD, XN, X, XNBH, R-line, RB, RQ, SB, RN, RNBH, RPT & WRSSV

13

rub lub cuab yeej

GS series thiab GR series

14

Plugs/Prong Running Tool Otis los yog CAMCO Running tool

1.875"- 5.813"

(Rau txhua hom ntsaws DD, X, XN, XNBH, RNBH, R, RN, RQ, RPT)

15

Kos lub cuab yeej

2 3/8" – 5 ½"

Rau lock mandrels

16

Gauge cutter

Rau txhua qhov ua tiav qhov ntau thiab tsawg

17

Lead impression block

1"- 5"

18

Qhov muag tsis pom lub thawv

1"-5"

19

Bailers

1 11/16" -3"

Hydrostatic, twj tso kua mis

20

Centralizers

2"-4"

npliag

21

Hlau finder / Grab / Scratcher / Txhuam

2" -5.5"

22

Mus Dab Ntxwg Nyoog

1 7/8"

tiaj tus, tshis ko taw

23

Cutter tuav

1 7/8" -2 ½"

24

Hloov Cov Cuab Yeej

2 3/8" – 5 ½"

Rau ib txwm thiab hnyav phab ntsa Xaiv thiab tsis xaiv

25

Magnets

Txhua qhov ntau thiab tsawg

26

Overshot

Txhua qhov ntau thiab tsawg

27

Kick over Tool

Txhua yam spec

28

Gas nqa Valve (GLV) Khiav / rub cov cuab yeej

1" & 1 ½"

Rau qhov luaj li cas

29

(BPV & TWCV) rub/running tool

Rau txhua lub tuam txhab ua tiav qhov ntau thiab tsawg

30

Tswb qhia

2 3/8" – 5 ½"

Rau nominal loj tubing

31

F dab tshos nres

2 3/8" – 5 ½"

nominal loj tubing

32

hmuv

2 3/8"- 7"

Rau nominal tubing / Liner qhov ntau thiab tsawg

33

Shock absorbers

Txhua qhov ntau thiab tsawg

34

Tubing puncher

Rau 3 ½ "thiab 4 ½" GRE TBG

3 ½ "GRE TBG Phab Ntsa Thickness=0.4175"

4 ½ "GRE TBG Phab ntsa Thickness=0.455"

35

Sand / Sample Bailers

Txhua qhov loj

36

Equalizing / Khiav / rub lub prongs

Rau plugs thiab Safety Valves

37

Dummy Bars rau SPM

1 "thiab 1 ½"

38

Hlau txhuam / Scratcher rau SPM

1 "thiab 1 ½"

39

Valve Catcher

2 3/8" – 5 ½"

nominal loj tubing

40

Junk Catcher

2 3/8" – 5 ½"

nominal loj tubing

41

Quick test sub

2 3/8" – 5 ½"

nominal loj tubing

42

Roller Bogie

2.77 "mus rau 4.900"

nominal loj tubing

43

Roller Bogie qia

3.000" & 3.600"

nominal loj tubing

44

Advanced Kickover cuab yeej

3.5" - 5.5"

nominal loj tubing

45

Block buster spring Jar

3.60" – 3.600"

nominal loj tubing

46

High Deviation Jar

2.275" 2.600",3.600"

nominal loj tubing

47

Low & High Loader Jar

1.700" - 5.940"

nominal loj tubing

48

Lubricator ntawm VR plug

Txhua qhov ntau thiab tsawg

49

Anti Blow-up Tool

2 3/8" – 5 ½"

nominal loj tubing
